Welcome to M&J Design Furniture's Trundle Storage Assembly Guide! Our goal is to ensure that assembling your trundle is straightforward, so you can enjoy its functionality for years to come. This guide includes step-by-step instructions with detailed photos to help you along the way.
Parts List:
- (1) Drawer Box
- (2) Drawer Sides
- (1) Back
- (1) Slat Pack Roll
Hardware Included:
- (12) 30mm Bolts
- (12) Cap Nuts
- (1) Allen Wrench
Step-by-Step Assembly Instructions
Step 1: Position Drawer Sides and Back
- Lay out the drawer sides and back as shown in Fig. A.
- Ensure all pieces are aligned correctly before proceeding.
Step 2: Insert and Secure 30mm Bolts
- Insert the 30mm bolts into the pre-drilled holes of the drawer sides and back.
- Secure the bolts in place using the cap nuts, as illustrated in Fig. B.
Step 3: Attach the Slat Pack
- Place the slat pack into the assembled frame, ensuring it is evenly aligned.
- Secure the slat pack with the provided wood screws, as shown in Fig. C.
- For further details, refer to the Slat Pack Assembly Instructions included with your package.
Instruction Photos Included
To make assembly even easier, we’ve included clear, step-by-step photos (Figs. A, B, C) in this guide. Simply follow the images for visual references at each step of the process.
Need More Help?
If you require additional support, visit our News & Support page to access more assembly guides and troubleshooting tips.
